SAE J517 R17 Wire Braided Hydraulic Hose
Internal hose: Synthetic rubber, extruded whole without joints, of uniform thickness
Reinforcement: 1 layer of high tensile steel wire braid up to size 1/2", 2 layers of high tensile steel wire braid from size 5/8" onwards
Covering: Anti-abrasive synthetic rubber, resistant to oils, fuels and atmospheric conditions
Working Pressure: 210 Bar / 3045 PSI
Impulse times: ≥ 150,000 Times
Media: Mineral and biological oils, glicol-water based, water, lubricants
| SIZE |
I.D. |
O.D. |
WORKING
PRESSURE
|
BURST
PRESSURE
|
BEND RADIUS |
WEIGHT |
Length Per PCS |
DASH
SIZE |
MM |
INCH |
MM |
MM |
BAR |
PSI |
BAR |
PSI |
MM |
KG/M |
METER |
| -03 |
4.6 |
3/16" |
4.6-5.4 |
11.6MAX |
210 |
3045 |
840 |
12180 |
45 |
0.455 |
50/100 |
| -04 |
6.4 |
1/4" |
6.2-7.0 |
13.2MAX |
210 |
3045 |
840 |
12180 |
50 |
1.190 |
50/100 |
| -05 |
8.0 |
5/16" |
7.7-8.5 |
15.0MAX |
210 |
3045 |
840 |
12180 |
55 |
0.200 |
50/100 |
| -06 |
9.5 |
3/8" |
9.3-10.1 |
17.0MAX |
210 |
3045 |
840 |
12180 |
65 |
0.260 |
50/100 |
| -08 |
12.7 |
1/2" |
12.3-13.5 |
21.1MAX |
210 |
3045 |
840 |
12180 |
90 |
0.390 |
50/100 |
| -10 |
16.0 |
5/8" |
15.5-16.7 |
25.9MAX |
210 |
3045 |
840 |
12180 |
100 |
0.640 |
50/100 |
| -12 |
19.0 |
3/4" |
18.6-19.8 |
30.3MAX |
210 |
3045 |
840 |
12180 |
120 |
0.790 |
50/100 |
| -16 |
25.4 |
1" |
25.0-26.4 |
38.6MAX |
210 |
3045 |
840 |
12180 |
150 |
1.250 |
50/100 |
