| Part |
I.D. |
O.D |
Rein. |
Max W.P. |
Weight |
Min.Bend Rad |
| Number |
in. |
mm. |
in. |
mm. |
Braids |
PSI |
BAR |
ib./ft |
KG/m |
in. |
mm |
| 4103 |
1/4 |
6.35 |
0.44 |
11.18 |
1 |
300 |
20.68 |
0.07 |
0.10 |
1.70 |
43.20 |
| 5/16 |
7.94 |
0.50 |
12.70 |
1 |
300 |
20.68 |
0.08 |
0.12 |
2.10 |
53.30 |
| 3/8 |
9.53 |
0.59 |
14.99 |
1 |
300 |
20.68 |
0.10 |
0.15 |
2.50 |
63.50 |
| 1/2 |
12.70 |
0.75 |
19.05 |
1 |
300 |
20.68 |
0.16 |
0.24 |
3.30 |
83.80 |
| 5/8 |
15.88 |
0.91 |
23.11 |
1 |
300 |
20.68 |
0.22 |
0.33 |
4.20 |
106.70 |
| 3/4 |
19.05 |
1.05 |
26.59 |
1 |
300 |
20.68 |
0.28 |
0.42 |
5.00 |
127.00 |
| 1 |
25.40 |
1.33 |
33.73 |
1 |
300 |
20.68 |
0.41 |
0.61 |
6.70 |
170.20 |
TUBE:PVC, smooth, medium oil resistance, RMA Class C
REINFORCEMENT:Synthetic braid
COVER:PVC, smooth, black, medium oil resistant,RMA Class C
BRANDING:Country of Origin
TEMPERATURE RANGE: -15°F(-26°C)to+150°F(+66°C)
FEATURES:Oil mist resistant tube , non-marking cover, Ozone, weather and UV resistant
APPLICATION:General purpose use, including air, water and mild chemical applications.
STANDARD LENGTHS:500 ft.
